Product Details
| Category | |
|---|---|
| Industry Category | Industrial Assembly Line |
| Application | Percussive Tools |
| Product Category | Hammer |
| Frequency of Application | Workshop - Medium |
| Dimension | |
|---|---|
| Length 1 -Imperial (inch) | 10.2 |
| Length 1 -Metric (mm) | 260 |
| Weight | |
|---|---|
| Imperial (lb) | 4.85 |
| Metric (kg) | 2.2 |
| Power | |
|---|---|
| Power Source | Compressed Air |
| Recommended Air Inlet Pressure (psi) | 90 |
| Recommended Air Inlet Pressure (bar) | 6.2 |
| Avg. Air Consumption (cfm) | 6.2 |
| Avg. Air Consumption (L/min) | 176 |
| Air Inlet (inch) | 1/4 |
| Air Hose I.D. (inch) | 3/8 |
| Motor | |
|---|---|
| Motor Type | Air Piston |
| Piston Stroke (inch) | 2 |
| Piston Stroke (mm) | 50 |
| Safety Requirements | |
|---|---|
| Machinery Safety Directives | 2006/42/EC |
| Risk Assessment & Risk Reduction | ISO 12100 |
| Safety Requirements | ISO 11148-4 |
| Noise Level | ISO 15744 |
| Vibration Level | ISO 28927-10 |
